Renesas Electronics Multi-Protocol Industrial Ethernet Switch
Renesas Electronics Multi-Protocol Industrial Ethernet Switch allows for easy transition between multiple common industrial Ethernet protocols. Renesas offers a complete solution for a multi-port high-performance industrial Ethernet switch with 24VDC supply and multiple industrial Ethernet protocol support.
Features
- Up to 5x Ethernet
- Multiple industrial Ethernet protocol support
- PROFINET, EtherNet/IP™, EtherCAT
- Integrated eMMC, DDR3 RAM and QSPI Flash
- Only 1x 24VDC (9V to 48V) supply required
- All other rails generated internally
- Only two components are needed to power the whole application
- Board space is reduced
Applications
- High-performance industrial Ethernet switch
- Industrial automation equipment
- Multi-protocol Ethernet switches or gateways
System Block Diagram
Additional Application Solutions
See how Renesas' complementary product portfolios of Embedded Processing, Connectivity, Analog, and Power work together to deliver comprehensive solutions.
